MEAN WELL PWM-60 LED Constant Voltage LED Driver

Mean Well PWM-60 LED Driver (60 W) — Constant Voltage / Dimmable / Class II

The Mean Well PWM-60 Series is a 60 W constant-voltage LED driver offering PWM-style output (approx. 1.47 kHz) and designed for LED strips, signage and decorative lighting systems. With universal AC input (90 – 305 VAC), IP67-rated housing and 3-in-1 dimming (0-10 V, PWM, resistance) or DALI variants, it is ideal for indoor and outdoor dimmable LED solutions.

Call for project quotations and trade discounts

Key Features

• ✅ Constant-voltage PWM-style output optimized for LED strip applications.
• ✅ Universal AC input: 90 – 305 VAC (or 127–431 VDC) for global compatibility.
• ✅ Fully encapsulated IP67 housing with Class II / double-insulation design.
• ✅ Built-in 3-in-1 dimming (0–10 Vdc, PWM signal, resistance) and DALI optional.
• ✅ Typical lifetime > 50,000 h
• ✅ 5-year warranty
• ✅ Protections including short-circuit, overload, over-voltage and over-temperature.

Output Voltages Options

• ☑️ 12 V (PWM-60-12)
• ☑️ 24 V (PWM-60-24)
• ☑️ 36 V (PWM-60-36)
• ☑️ 48 V (PWM-60-48)

Dimming Options

• ☑️3 in 1 (0–10 Vdc, PWM signal, resistance)
• ☑️ DALI 2 (Fully compatible with both DALI2 and DALI Min. dimming level 0.2%)

Applications

• ✅ LED strip lighting for signage, cove and decorative accent lighting.
• ✅ Indoor/outdoor linear fixtures with dimming capability.
• ✅ Retrofit LED module systems requiring constant-voltage dimmable drivers.

Why Choose the PWM-60 Series?

• ✅ Provides an excellent 60 W constant-voltage driver tuned for LED strip applications where PWM fidelity matters.
• ✅ Compact Class II design simplifies installation with no earth ground required.
• ✅ Strong dimming flexibility and IP67 rating make it suitable for both indoor and outdoor environments.

View manufacturer page on MeanWell.com
